Main features:
1. Single nail, double nail, and reinforced nail can be completed in one go.
2. A dual-purpose box that can nail single, double, and irregular cardboard boxes.
3. The paper feeding section automatically counts and bundles them into bundles for delivery.
4. Imported brand PLC control system.
5. Adjust the nail spacing and use the computer to automatically adjust the nail spacing.
6. All bearings are imported from Japan NSK.
7. Suitable for three, five, and seven layer cardboard boxes, with or without a bottom cover, can also be nailed.
8. The operation of nailing semi-finished products into finished products is simple and convenient, reducing wages.
9. Automatic counting in the later stage. The number of finished products can be stacked and sent to the end of the conveyor according to the set quantity (1-99).
10. It adopts touch screen control, and the nail distance can be directly set on the touch screen for convenient operation.
11. The whole set of nail heads is imported from Taiwan, all made of Japanese imported mold steel and precision processed by computer gongs.
12. The bottom mold and blades are made of tungsten steel imported from Japan (wear-resistant).
All electrical appliances inside the control box are from well-known brands.
14. The button switch and travel switch are Schneider Omron brand.
15. All pneumatic components are imported from Taiwan.
16. All synchronous belts are imported from Germany.

17.20KG large flat wire reel and small flat wire reel can be used interchangeably.
